Warn ZEON XC 12 12,000 lb. Steel Rope Winch (110412)

The Warn ZEON XC 12 12,000 lb. Steel Rope Winch (110412) from Nomadic Supply Company® delivers authentic ZEON-grade performance in a compact package purpose-built for tight bumper spaces. The ZEON XC’s signature innovation is its relocated control pack — mounted below the tie plate rather than on top — giving your full-size truck a lower, cleaner profile without sacrificing an ounce of recovery capability.

Pre-spooled with 80 ft. of 3/8 in. galvanized steel rope, the Warn ZEON XC 12 12,000 lb. Steel Rope Winch (110412) is ready to work right out of the box. Its 176:1 three-stage planetary gear train, Albright contactor, and IP68/IP69K sealed construction ensure it’s ready for any recovery situation. Every ZEON XC is expertly assembled in Clackamas, Oregon, USA, and backed by Warn’s industry-leading limited lifetime mechanical / 7-year electrical warranty.

Warn ZEON XC 12 12,000 lb. Steel Rope Winch (110412) Features:

• Compact XC design: The ZEON XC packs full ZEON-grade performance into a smaller footprint, with the control pack relocated below the tie plate to save critical bumper space.
• 12,000 lb. rated line pull: Engineered for full-size trucks and heavy builds — serious recovery capacity for the most demanding recovery situations.
• 80 ft. steel rope included: 3/8 in. galvanized steel rope pre-spooled and ready for the trail — proven durability in the harshest recovery conditions.
• IP68 / IP69K waterproof rating: Fully submersion- and high-pressure-spray-rated through automotive-grade O-ring seals throughout for operation in any conditions.
• Albright contactor: OEM-grade electrical reliability rated for thousands of winching cycles.
• OEM-grade corrosion resistance: OE-grade paint and fasteners resist fading and corrosion season after season.
• Free-spooling clutch: Quickly hand-spool rope out without running the motor.
• Wired remote included: Ruggedized corded 12 ft. remote for safe operation from a distance.
• Industry-leading warranty: Limited lifetime mechanical warranty and 7-year electrical warranty backed by Warn’s global service network.
• Assembled in the USA: Designed, engineered, and assembled at Warn’s facility in Clackamas, Oregon, USA.

Warn ZEON XC 12 12,000 lb. Steel Rope Winch (110412) Includes:

• Warn ZEON XC 12 12,000 lb. Steel Rope Winch (110412)
• 80 ft. × 3/8 in. galvanized steel rope
• Hawse fairlead
• Wired remote (12 ft. lead)

Warn ZEON XC 12 12,000 lb. Steel Rope Winch (110412) Specifications:

• Rated Line Pull: 12,000 lb.
• Motor Type: Series Wound
• Voltage: 12V
• Gear Train: 3-Stage Planetary
• Gear Ratio: 176:1
• Brake Type: Automatic Cone
• Solenoid Type: Albright Contactor
• Rope Type: Steel
• Rope Diameter: 3/8 in.
• Rope Length: 80 ft.
• Fairlead Type: Hawse
• Free Spooling: Yes
• Remote Included: Yes
• Remote Type: Wired (12 ft. lead)
• Waterproof Rating: IP68 / IP69K
• Overall Length: 22 in.
• Overall Width: 6.7 in.
• Overall Height: 7.8 in.
• Mounting Bolt Pattern: 4-bolt, 4.5 in. × 10 in.
• Color: Black
• Assembly: Clackamas, Oregon, USA
